Cyclone Separator
🌀

Cyclone Separator Calculator

Multi-Cyclone Design per GPSA

Cyclone & Multi-Cyclone Separator Sizing
Size single cyclone or multi-cyclone bundle separators using centrifugal separation principles per GPSA. Calculates cyclone dimensions based on Lapple model, cut diameter, collection efficiency, and pressure drop. Suitable for particulate removal, mist elimination, and high-velocity gas applications.

Operating Conditions

Gas Properties

Leave blank to auto-calculate

Particle/Droplet Properties

Liquid ~50-65 lb/ft³, Solids ~100-200 lb/ft³
Particles larger than this are 50% removed

Design Parameters

Typical range: 50-100 ft/s

📚 Learn the Theory

Understand cyclone separation principles, Lapple model, cut diameter calculations, and multi-cyclone arrays

Read Engineering Guide →

Quick Reference

  • Single Cyclone: High flow, lower efficiency
  • Multi-Cyclone: Multiple small cyclones, higher efficiency
  • Axial Flow: Compact, inline installation
  • Cut Size: 50% collection efficiency point
  • ΔP Range: Typically 2-6 psi for cyclones

Frequently Asked Questions

What is a cyclone separator used for?

Cyclone separators use centrifugal force for high-efficiency removal of particulates and liquids from gas streams in midstream applications.

What standards does this cyclone separator calculator follow?

This calculator sizes cyclone and multi-cyclone separators per GPSA standards for particulate and liquid removal.

What is a multi-cyclone separator?

A multi-cyclone uses multiple smaller cyclone tubes in parallel to achieve higher efficiency and handle larger gas volumes than a single cyclone.
